Outboard Bracket - Fixed Mount, Platform OU06

High-Quality Construction: Crafted from lifetime marine-grade 3mm stainless steel for exceptional durability.

Varnished Hardwood Mounting Plate: Provides a secure and aesthetically pleasing surface for motor attachment.

Fixed Design: Allows most auxiliary/trolling motors to tilt up without touching the transom.

Angled Side Brackets: Side brackets are angled up ten degrees to compensate for the transom angle, ensuring proper alignment.

Easy Installation: Pre-drilled mounting holes facilitate straightforward installation

Model: OU06.

Material: Marine-grade 3mm stainless steel with varnished hardwood mounting plate.

Dimensions:

Overall Width: 235mm.

Overall Length: 295mm.

Timber Size: 220mm (width) x 160mm (height) x 35mm (thickness).

Mounting Hole Spacing:

Horizontal: 190mm (center to center).

Vertical: 123mm (center to center).

Hole Diameter: 11mm (suitable for 10mm (3/8") mounting bolts).

Weight Capacity:

Standard Shaft Motors: Up to 10hp or 38kg.

Long Shaft Models: Up to 8hp maximum.

Country of Manufacture: New Zealand
