Ronstan 75mm Core Block Aluminium Wire Rope Sheave RF74100

The Ronstan 75mm Core Block Aluminium Wire Rope Sheave RF74100 delivers class-leading performance with minimal friction.

Its universal head articulates fully across three axes, with head posts lockable at 0 or 90 degrees using a 2.5mm hex key for precise rigging control.

The central hub hole serves as a becket take-off or tie-up point, adding versatility to your setup. Engineered for both dynamic and static loads, this sheave combines contemporary styling with exceptional durability. Sheave diameter 75mm accommodates rope up to 14mm. Pin diameter 8mm. Maximum working load 1500kg, breaking load 3000kg. Weight 354g. An alloy rope/wire sheave version is also available for alternative applications.

Sheave Ø: 75 mm
Max. Rope Ø: 14 mm

Pin Ø: 8 mm
M.W.L: 1500 kg
B. L: 3000 kg
Weight: 354 g
